一氧化氮傳感器NO-D4
- 產品品牌 Alphasense
- 產品型號 NO-D4
- 產品描述 測量范圍：100ppm，靈敏度：500-750nA/ppm，響應時間：<10s，線性范圍：+/-1.5ppm，過載：200ppm，分辨率：0.1ppm...
Nitric Oxide
Alphasense Nitric Oxide gas sensors operate using proven fuel cell technology.
Sensors are available in the following sizes:
A: 20mm diameter, the industry standard size for portable gas detectors
B: 32mm diameter package, the best choice for fixed site applications
D: miniature, with proven long-term performance. Sensors designed for the next generation of portable gas detectors.
The NO range provides OEMs with reliable sensors for use in a number of high volume applications. Strong signal levels combined with low zero current allows resolution to 200 parts per billion (ppb) whilst giving linear outputs to as high as 250ppm. The sensors are suitable for inclusion in fixed installation sensing heads, portable safety instruments, urban air monitoring and stack gas analysers.
Alphasense NO sensors provide a significant improvement in stability of response to transient relative humidity changes.
The NO sensors offer our electrolyte leak-free guarantee and reliable long-term detection performance. The leakproof housing is moulded with a colour coded top for ease of identification.
Data sheets
Go to downloads page
| FILE NAME | DESCRIPTION | TYPE | DOWNLOAD LINK |
|---|---|---|---|
| NO-D4 | Miniature | Data Sheet |  |
| NO-B4 | Compact, 4-electrode, low ppb | Data Sheet | |
| NO-B1 | Compact, filtered | Data Sheet | |
| NO-AE | Small, high concentration | Data Sheet | |
| NO-A4 | Small, 4-electrode, low ppb | Data Sheet |  |
| NO-A1 | Small | Data Sheet | |
